Features
- Detection range 0 to 393.70 in
- Sound speed: 1000 to 15,000 m/s
- Compact size: 9.45 in × 5.91 in × 1.97 in
- Lightweight: 1.6 kg
- Operating temperature: -10 °C to 50 °C
- High accuracy flaw detection
Technical Specifications
| Title | Parameter |
| Reject | 0% to 80% of screen height, step: 1% |
| Vertical Linear Error | ≤ 3% |
| Horizontal Linear Error | ≤ 0.2% in the scanning range |
| Sensitivity Leavings | ≥ 62 dB |
| Dynamic Range | ≥ 34 dB |
| Alarm | Three modes: forbidden wave, loss wave, auto |
| A-Scan Display Area | Full screen or local |
| A-Scan Functions | Display freezing and de-freezing, A-Scan filling |
| Data Save | 300 A-Scan images (including instrument settings) |
| PC Interface | RS232 or USB |
| Measuring Unit | mm or inch |
| Battery | Li battery 7.4V, 4800 mAh |
| Power Adaptor | Input: 100V to 240V / 50Hz to 60Hz Output: 9V DC / 1.5A |
| Port Type | BNC or LEMO |
| Working Humidity | 20% to 90% |
| Working Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Weight | 3.75 lb (1.7 kg) |
| Size (H × W × D) | 9.45 in × 5.91 in × 1.97 in (240 mm × 150 mm × 50 mm) |
