Features
- High accuracy AC leakage current measurement
- Peak hold function to capture maximum current values
- Data storage for up to 99 measurement groups
- Magnetic shielding technology for strong anti-interference
- Clear LCD display with data hold and overflow indicators
- Automatic frequency detection (50Hz/60Hz)
- Low power consumption with auto shut-off after 5 minutes
- Battery voltage indicator for timely replacement
- Lightweight and compact design for easy handling
Technical Specifications
| Power Supply | DC 3V Alkaline dry battery LR03 x 2 pcs |
| Measurement Range | 0.000 mA to 60.0 A |
| Resolution | 1 µA |
| Measurement Accuracy | ±1.5% reading ±5 digits @ 73 °F to 84 °F (23 °C to 29 °C), below 70% RH |
| Sampling Rate | 2 times per second |
| Frequency | 50 Hz or 60 Hz automatic identification |
| Data Storage | 99 groups; flash display “FULL” symbol indicates storage full |
| Peak Hold | Peak capture and hold; long press HOLD key displays peak value |
| Data Hold | Data hold function; “DH” symbol displayed |
| Overflow Display | Exceed measure range overflow indicated by “OL” symbol |
| Automatic Shut Down | Shuts down automatically after 5 minutes of inactivity |
| Battery Voltage Alert | Displays low battery symbol below 2.8V |
| Working Current | 5 mA |
| Line Voltage | Measures below AC 600 V circuit |
| Shift | Automatic |
| Operating Temperature | 32 °F to 104 °F (0 °C to 40 °C) |
| Weight | 0.71 lb (0.32 kg) |
| Dimensions | 6.77 in x 2.80 in x 1.26 in (172 mm x 71 mm x 32 mm) |
| Current Transformer Size (CT) | 0.98 in x 1.18 in (25 mm x 30 mm) |
| LCD Size | 1.38 in x 0.85 in (35 mm x 21.5 mm); display area: 1.26 in x 0.59 in (32 mm x 15 mm) |
