Technical Specifications
| Sensor | Piezoelectric Sensor |
| Measuring Range | Acceleration 0.01 m/s2 to 200 m/s2 Equivalent Peak Velocity 0.01 m/s to 200 m/s True RMS Displacement 0.000039 in to 0.079in (0.001 mm to 2.0mm) Equivalent Peak-Peak |
| Frequency Range | Acceleration 10 Hz to 1 kHz, 10 Hz to 10 kHz Velocity 10 Hz to 1 kHz Displacement 10 Hz to 1 kHz |
| Accuracy | <5% |
| Analogue Output | AC Output 0.0 V to 2.0 V Peak Full Scale (Load Resistance: Above 10 kΩ) |
| Data Output | USB, RS-232, Bluetooth |
| Operation Conditions | Temperature 14 °F to 122 °F (0 °C to 50 °C) Humidity <90% RH |
| Power Supply | 4 AA 1.5 V (UM-3) battery |
| Dimensions | 6.3 in x 2.68 in x 1.26 in (160 mm x 68 mm x 32 mm) |
| Weight | 0.4 lb (181 g) |
