Overview
ETC Digital Handheld Portable Vibration Meters are versatile device designed for measuring vibration levels. It offers a digital display for easy reading of vibration measurements. With its handheld and portable design, it provides convenience and flexibility for on-site testing. The meter is suitable for various applications, including machinery monitoring, equipment maintenance, and vibration analysis.
Features
- Full display.
- Screen flipping.
- Switch acceleration measurement between high and low frequency; high frequency (1KHz to 10KHz) low frequency (20Hz to 1KHz).
- Curve display.
- Power indicator.
- Double measurement button.
- Screen brightness
- Shutdown time setting.
- Machinery grade.
Technical Specifications
| Vibration acquisition | Piezoelectric ceramic accelerometer (shear type) |
| Measurement range of acceleration | 0.1 to 199.9 m/s2 peak |
| Measurement range of speed | 0.1 to 199.9 mm/s RMS |
| Measurement range of displacement | 0.001 to 1.999 mm peak -peak value |
| Measurement error | ±5%±2digits |
| Frequency range of acceleration measurement | High frequency: 1 kHz to 15 kHz (HI);Low frequency: 20 Hz to 1 kHz (LO) |
| Frequency range of speed measurement | 20 Hz to 1 kHz (LO) |
| Frequency range of displacement measurement | 20 Hz to 1 kHz (LO) |
| LCD display | color display |
| Shuffle interval of data display | 1 second |
| Maximum groups of data storage | 7 groups |
| Power supply | 1.5 V AAA battery x 2 |
| Temperature range for operation | 32 to 104 °F (0 to 40 °C) |
| Humidity range for operation | 30 to 90 % RH |
| Size | 7.08 in x 2.12 in x 1.18 in (180 mm x 54 mm x 30mm) |
| Weight | 0.55 lb. (250 g) (with batteries) |
