Overview
Enviro Test Consrtuct Dual Coating Gauge is a professional measurement of metal material surface coating layer thickness of the major object of non-destructive testing equipment. According to the different metal substrates using different measuring methods. Magnetic thickness method, can be nondestructively measuring magnetic metal matrix.
Features
- The use of alloy integrated probe
- Fast testing speed and high sensitivity
- Exquisite artificial integration design
- Continuous testing and single measurement
- Statistical functions
- Which can store 2000 measurement data
- Can connect to the computer
- Zero calibration and two point calibration modes
- Beep prompts in operation process
- Low voltage indication
Technical Specifications
| Measuring Range | 0 μm to 1500 μm |
| Using Environment | 32 °F to 122 °F (0 ℃ to 50 ℃) 20% RH to 90% RH |
| The Thinnest Matrix | 0.15 in (0.4 mm) |
| Measurement Accuracy | ± (3%H + 1.5μm) |
| Resolution Ratio | 0.1μm / 1μm |
| Power | 3 (7) alkaline battery |
| Size | 4.9 in x 2.5 in x 1.1 in (126 mm x 64 mm x 28 mm) |
| Weight | 0.23 lb. (106 g) |
