Features
- Intelligent convertor
- Circuit design effectively
- Connection method
- Measurement electrode design
Technical Specification
| Nominal Diameter | Pipe PTEE lining: DN 10 to DN 500 Pipe Rubber lining: DN 65 to DN 1200 |
| Precision level | ±0.5% / ±1% |
| Repeatability error | Measured value ±0.1% |
| Medium Temperature | Conventional rubber lining: -4 °F to 140 °F (-20 °C to 60 °C) PTEE lining: -4 °F to 120 °F (-20 °C to 120 °C) |
| Rated working pressure | 87.02 PSI (0.6 Mpa), 145.03 PSI (1.0Mpa), 232.06 PSI (1.6 Mpa), 580.15 PSI (4.0 Mpa) |
| Velocity range | 0.3 m/s to 0.5 m/s |
| Conductivity range | ≥5 us/cm |
| Signal output | 4 mA to 20 mA, pulse, RS 485 |
| Power supply | AC 220 V, DC 24 V,Battery |
| Installation requirements for straight pipe segments | upstream ≥10 DN, downstream ≥5 DN |
| Connection type | Flange, Thread, Clamp |
| Protection Level | IP 65 (IP 68 can be customized) |
| Environment temperature | -13 °F to 140 °F (-25°C to 60 °C) |
| Power consumption | ≤20 W |
