Mass Flow Meter with Controller (Real-time Out, 60 Gas, Black)

Mass Flow Meter with Controller (Real-time Out, 60 Gas, Black)

Enviro Test Construct Mass Flow Meter with 60 Gases measures mass flow rate of 60 gases moving through a tube with real-time curve output.

SKU: ETC00Y600ZY Category:

Key Features

  • Very low zero drift and temperature drift
  • It can measure over 60 types of gas
  • User can set medium parameters / customize flow range / customize low pressure difference / real-time curve output
  • User can select different color
  • User can collect data into EXCEL form. Controlling form: RS232 / RS485 / 0-5V / 4-20MA / different section control / different section combination / High-low level alarm.

Technical Specifications

Flow range(0-5,10,20,30,50,100,200,300,500) SCCM (0-1,2,3,5,10,20,30,50,100)SLM
Accuracy1%FS
Linearity0.5%FS
Repeatability0.2%FS
Responding timeLess than 1s
Pressure difference(0.0500.3) Mpa
Max. Pressure10MPa
Working temperature41°F ~ 149°F
Input/output DigitalRS232/RS485
Analog0-5vdc or 4-20mA
Power Supply7-16vdc,1A
Weight1.0kg
