Overview
Enviro Test Construct Ultrasonic Liquid Flow Meter is on the basis of pipeline electromagnetic flow meter developed a kind of new flow meter. After adopting the technology of pressure opening and pressure installation, the plug-in electromagnetic flow meter can be installed without stopping water and can also be installed on cast iron pipes and cement pipes. The successful development of plug-in electromagnetic flow meter provides a new method for fluid flow measurement.
Technical Specifications
| Pipe Diameter | 11.81 in to 118.11 in (300 mm to 3000 mm) |
| Flow Rate Range | 0.1 m/s to 10 m/s |
| Sensor Material | Stainless steel |
| Conductivity | >50 uS/m |
| Straight Pipe | Front 5 DN, Behind 3DN |
| Medium Temperature | 68 °F to 266 °F (-20 ℃ to +130 ℃) |
| Ambient Temperature | 68 °F to 144 °F (-20 ℃ to +60 ℃) |
| Withstand Voltage | 1.6 mPa |
| Protection Class | IP65 (Integrated) IP68 (Split type) |
| Signal Output | 4 mA to 20 mA, RS485, HART, MODBUS |
