Technical Specifications
| Accuracy | Better than ±1% |
| Repeatability | Better than 0.2% |
| Principle | Transit-time measuring principle |
| Measurement Period | 500ms |
| Display | LCD with backlight, display accumulated flow/heat, instantaneous flow/heat, velocity, time etc. |
| Output | Analogue output: 4 to 20mA or 0 to 20mA current output. Impedance 0 to 1kW. Accuracy 0.1%. |
| OCT output: Frequency signal (1 to 9999HZ) | |
| Relay output: over 20 source signal (no signal, reverse flow etc.) | |
| RS485 serial port | |
| Power Supply | AC220V or DC24V |
| Power Consumption | Less than 1.5W |
| Protocols | MODBUS, M-BUS, Fuji extended protocol and other factory protocol |
| Humidity | Main Unit: 85% RH |
| Transducer: water-immersible, water depth less than 3m |
