Technical Specifications
| Flow Range | 0 m3/h to 93 m3/h (And determine the range with weir tank specifications) |
| Weir Trough type | Triangular weir, rectangular weir, Full width weir, Parshall flume |
| Display Accuracy | Depending on the input signal. The flow error related with weir trough: Triangular weir :1 to 2%; Rectangular weir: 1 to 4%; Parshall flume: 3% |
| Display | 2.8 inches LCD display, it can display height of liquid level, Instantaneous flow rate, cumulative flow, time flow, daily flow, year flow, month flow, date, month and year, the battery level (Can be arbitrarily set) |
| Signal Output | 4 mA to 20 mA, RS485/ RS232 |
| Relay Contact Capacity | AC:5 A 120 V DC:10 A 24 V |
| Power Supply | Working power: DC 24 V, or AC 160 V to 250 V Normal power: <5 W |
