Overview
Enviro Test Construct Touch Screen LCD Display Module is a 7-in TFT LCD display module with a built-in touch screen and HDMI interface. It offers high-resolution, crisp image quality and intuitive touch interaction. The HDMI interface makes it easy to connect to compatible devices for a wide range of applications, such as interactive kiosks and control panels
Features
- High-resolution touch screen
- LCD technology
- Responsive touch interface
- Bright and clear visuals
- Multi-touch capability
- Durable construction
- Compact design
- Wide viewing angles
- Easy integration
- User-friendly interface
Technical Specifications
| Backlight Type | LED |
| Brightness | 300 cd / m2 |
| Viewing Angle | 70°/70°/50°/70°(L/R/U/D) |
| TFT Panel | A Class Industry Panel |
| Touch Screen | 4 Wire Resistance Touch /Capacitive Touch / Without Touch Screen |
| Serial Interface | R S232 / R S422 / R S485 / TTL level |
| Wireless interface | WIFI (Optional) |
| Ethernet interface | 10 M / 100 M (Optional) |
| Project file Downloading | USB 2.0 port or U storage Disk |
| UART Port | RS 232 / RS 422 / RS 485 / TTL |
| Network Port | Ethernet Port / WIFI |
| Flash Memory | Standard 256 MB, Extend 1 GB or 2 GB |
| USB port | Online Download By USB Cable |
| U Storage Disk Interface | Offline Download or Copy User Data |
| Touch Screen | 4 Wire Resistance / Capacitive |
| Vector Font | Standard TTF Format |
| Image | Support PNG/JPG/BMP/SVG/GIF Format |
| Audio Interface | The length of single audio file is not limited, theoretically up to 4096 audio files, speaker power is 8 ohms 2 watts or 4 ohms 3 watts |
| Voltage(V) | DC 5.0-28 |
| Flash | 256 MB |
| Network | Ethernet/Wi-Fi/BT |
| Interface | RS 232RS 422RS 485 TTL |
| Brightness | 300 cd / m2 |
| Power(W) | 2.6 W |
| CPU | Cortex A8 1Ghz |
| Display Size | 7 in |
| Size | 7 in |
| Resolution | 800 × RGB × 480 |
| Pixel Spacing | 0,02 in x 0,07 in (0.064 mm × 0.179 mm) |
| Color | 262,144 colors (18 bit) |
| Viewing Area | 6,06 in x 3,38 in (154.08 mm × 85.92 mm) |
| Display Dimension | 7,33 in x 4,15 in (186.4 mm x 105.5 mm) |
| Net Weight | 0,66 lb (300g) |
