Overview
Enviro Test Construct temperature measuring infrared is the latest tool thermal imager introduced by the company. Simple appearance, at the same time in line with the human body. Designed, easy to operate, no training required. High-cost performance design, rich functions, reliable performance, accurate temperature measurement. To be effective Improving the efficiency of testing work is a powerful tool to ensure the production process and product quality in the industrial field.
Features
- Real-time video
- Center points temperature measurement
- Regional maximum/minimum temperature measurement
- Area high/low temperature overtemperature alarm
- Correction of reflectance
- Humidity is adjustable
- Distance is adjustable
- Ring temperature is adjustable
- Emissivity is adjustable
- Temperature range is adjustable
- 6 palettes
- Lithium battery with 4 hours of use
Technical Specification
| Resolution | 160 pixels × 120 pixels |
| Camera Lens | 0.43 in x 0.27 in x 1.18 in (11 mm x 7 mm x 30 mm) |
| Frame Rate | 25 Hz |
| Screen | LCD |
| Display | 320 × 240 |
| Charging | Unit charging |
| Electron Amplification | ×2, ×4 |
| Temperature Measurement Range | -4 °F to 662 °F (-20 °C to 350 °C) |
| Temperature Measurement Accuracy | ±35.6 °F (±2 °C) / ±2% |
| Operating Temperature | -4 °F to 122 °F (-20 °C to 50 °C) |
| Size | 4.05 in x 3.85 in x 10.15 in (103 mm × 98 mm × 258 mm) |
| Weight | 1.65 lb (710 g) |
