Technical Specifications
| System requirements | Windows® 10; Windows® 8; Windows® 7 |
| Product-/housing material | PC – ABS |
| Focus | Fixed focus |
| Infrared resolution | 160 x 120 pixels |
| Image refresh rate | 9 Hz |
| Super Resolution (IFOV) | 2.1 mrad |
| Super Resolution (Pixel) | 320 x 240 pixels |
| Geometric resolution (IFOV) | 3.4 mrad |
| Minimum focus distance | <0.5 m |
| Field of view | 31° x 23° |
| Thermal sensitivity | 120 mK |
| Spectral range | 7.5 µm to 14 µm |
| Display option | IR image only |
| Colours | 4 (iron, rainbow, cold-hot, grey) |
| Display type | 8.9 cm (3.5″) TFT, QVGA (320 x 240 pixels) |
| Housing protection class | IP54 |
| Vibration | 2 G |
| Air humidity | 20 to 80 %RH non-condensing |
| Storage temperature | -22 °F to 140 °F (-30 °C to 60 °C) |
| Operating temperature | 5 °F to 122 °F (-15 °C to 50 °C) |
| Size | 8.62 in x 3.77 in x 3.74 in (219 mm x 96 mm x 95 mm) |
| Weight | 1.12 lb (510 g) |
