Overview
Enviro Test Construct Radiation Pollution Detector is a portable radioactive measuring instrument, which is mainly used for the measurement of α, β pollution on radioactive surfaces and the dose rate of x γ rays. The instrument can be widely used in environmental protection departments, law enforcement departments of security supervision, radioactive departments of hospitals, nuclear power stations, and clothing of personnel Measurement of α and β surface contamination of test benches and test equipment in order to decontaminate in a timely manner, and at the same time, it can also detect environmental grade x γ-ray dose rates.
Features
- Measures ionizing radiation types (alpha, beta, gamma) in real-time
- Provides clear visual and audible alarms for unsafe levels
- Offers data logging, connectivity, and geotagging for analysis and remote monitoring
- Portable design with calibrated accuracy and durable construction
- Sound and light alarm, alarm threshold continuously adjustable
- Fault intelligent display
- Graphic dot matrix LCD display with backlight
- Continuously adjustable timing time
- Battery under voltage display
- Integrated design of probe host, easy to use
Technical Specifications
| Detector | Flat double scintillation detector (optional end window counting tube) |
| Stability | ≤±10% |
| Display time | cps, cpm , Bq / cm2 |
| Measure time | 1 s to 999 s adjustable |
| Effective area | 170 cm2 |
| Measuring range | α, β 0.00cps to 105 cps α, β 0.00 Bq / cm2 to 106 Bq / cm2 α, γ 0.1μ Gy / h to 500μ Gy / h |
| Background | α: ≤1 cps, β: ≤10 cps |
| Detection efficiency | 90 Sr to 90 Y, ≥60%, 239 Pu, ≥20% (grid to be protected, 2π) |
| Power supply mode | 4 AA type 1.5 V batteries (optional rechargeable battery |
| Power supply mode | Battery |
| Working conditions | Temperature range: 14 ℉ to 122 ℉ (-10 ℃ to + 50 ℃) Relative Humidity: 95% RH |
| size | 9.44 in x 4.72 in x 7.87 in (240 mm x 120 mm x 200 mm) |
| Weight | 2.09 lb (950 g including battery) |
