Overview
Enviro Test Construct Portable Radiation Detector survey meter uses a ZnS coated scintillation detector that can be fixed or moved and detects surface contamination directly or indirectly. Mainly used for the detection of radioactive workplace and laboratory worktable, floor, wall, hands, clothes, shoes and other surface by alpha or beta radioactive pollution, widely used in environmental protection, public security, military, customs, ports, health, nuclear industry, nuclear power plant system.
Features
- New plastic scintillator detector, not inflatable
- Built in Geiger miller tube gamma ray detector
- Simultaneous measurement of alpha and beta / gamma without additional probes
- Indicates that sound frequency is proportional to activity
- Large area lcd digital display
- The probe and the host are connected by a telescopic cable
- Small size, light weight, easy decontamination, can adapt to the field and laboratory environmental conditions
- Optional Bluetooth, Wi-Fi data transmission
- Optional Bluetooth printer
Technical Specifications
| Display units | CPS, Bq, Bq/cm2, mu Sv/h |
| Detector type | 100 cm2 ZnS dual flash detector |
| Measuring range | 0 CPS to 9999 CPS |
| The measurement area | 100 cm, 2 |
| Data storage | the built-in memory can store 20000 data |
| Alarm function | Independent alarm threshold can be set respectively for alpha and beta |
| Detection efficiency | E = 30% (2 pi, alpha phi 50239Pu source) E beta = 40% (2 pi, Phi 50, 90Sr-90Y source) The relative error less than 20%. |
| Product configuration | main machine, probe, connecting cable, waterproof portable case |
| Stability | 8 hours continuous work < 10% |
| Work environment | the environment temperature of-10 DEG C 50 |
| Power source | built in rechargeable lithium battery |
| Background | Alpha: 0.1 CPS beta / gamma 15 CPS to 25 CPS The relative humidity is less than or equal to 95% |
| Weight | 1.98 lb (0.9 Kg) |
