| Spectral range | 8 um to 14 um |
| Resolution | 384 Pixel x 288 Pixel |
| Frame rate | 50 Hz to 60 Hz |
| Focal | Manual |
| Visual camera built-in | 3.2 M pixels, CMOS |
| Spatial resolution | 5 mrad |
| Visual camera | Yes |
| LCD | 3.5″ TFT LCD, 640 Pixel x 480 Pixel |
| Color palette | 11 Color palettes for option (iron, rainbow,black hot, white hot and so on) |
| Adjustment | Auto or Manual |
| Measure mode | Up to 4 movable spots,3 movable area (maximum & minimum temp. capture, average temp. measure), line temp. measure, isotherm analysis, temp. difference measure, overheated alarm(voice, light) |
| Emissivity | Variable from 0.01 to 1.0 (increment: 0.01)or predefined emissivity options |
| Settings | Data or time, ℃ / ℉ / K, language |
| Memory card | 8 G Micro SD(TF) card, maximum 16 G |
| Storage method | Manual or auto single frame photo saving,visual, thermal relative saving |
| File format | Thermal JPEG, with original digital dataVisual JPEG |
| Battery | rechargeable Li-ion battery |
| Operation time | Around 4 hrs continuous operation |
| Charging | Smart charger or other options (AC poweradapter or DC 12 V in-car power) |
| Energy-saving mode | Auto sleep, auto shut down |
| Power input | DC 12 V |
| Memory card | Micro SD (TF) card slot |
| Video output | Yes, PAL or NTSC |
| Protection grade | IP-54 |
| Vibration resistance | 2 G, IEC68-2-6 |
| Drop resistance | 2 m |
| Range | -4 °F to 1202 °F (-20 ℃ to +650 ℃) |
| Accuracy | 35.6 °F (±2 ℃) or ±2% |
| NETD | 32.09 °F (0.05 ℃) at 86 °F (30 ℃) |
| Working temp. | 5 °F to 122 °F (-15 ℃ to +50 ℃) |
| Storage temp. | -13 °F to 158 °F (-25 ℃ to +70 ℃) |
| Humidity | ≤95% non-condensing |
| Dimension | 9.05 in × 4.13 in × 9.64 in (230 mm × 105mm × 245 mm) |
| Weight | 2.16 lb (980 g) |
