Overview
Enviro Test Construct multifunctional process multiproduct calibrator is a multi-function calibrator, integrates AC and DC voltage source, AC and DC current source, DC resistance source, etc. The accuracy class is 0.05. It’s applied to calibrating 3.5 digits multimeter, voltmeter, ammeter, ohmmeter etc.
Technical Specifications
| Accuracy | Class 0.05 |
| DC Voltage Output | 20 mV to 1100 V |
| DC Current Output | 2 μA to 22 A 33 A |
| AC Voltage Output | 20 mV to 1100 V |
| AC Current Output | 200 μA to 22 A, 33 A |
| Sinusoidal Wave Frequency | 45 Hz to 1100 Hz |
| Simulated DC Resistance | 10 Ω to 220 MΩ |
