Technical Specifications
| Use environment | Input Power Supply | 220 V ± 10% 50 Hz ± 10% |
| Atmospheric Pressure | 86 Kpa to 106 Kpa | |
| Temperature | 14 °F to 113 °F (-10 ℃ to 45 ℃) | |
| Humidity | ≤ Q 80% RH | |
| Safety performance | Insulation Resistance | > 2MΩ |
| Dielectric Strength | Power supply on the chassis power frequency 1.5 kV withstand voltage for 1 minute, no flashover and arcing | |
| Basic parameters | Time | Range：16000.0 ms, Resolution: 0.1 ms Error: 1. within 200 ms, 0.1 ms ± 1 word 2. 200 ms or above, ± 2% 3. The same period, ± 0.1ms |
| Speed | Range：20.00 m/s, Resolution 0.01 m/s error：1. within 0 m/s to 2 m/s，± 0.1 m/s ± 1 digital 2. 2 m/s or above, ± 0.2 m/s | |
| Stroke | Vacuum circuit breaker: Range: 50.0 mm Resolution: 0.1mm, error: ± 0.5 mm SF6 circuit breaker: Range: 300.0 mm，Resolution：0.1 mm error：± 2 mm Less oil circuit breaker：Range：600.0 mm，Resolution：0.1 mm error：± 2 mm | |
| Current | Range：20.00A ，Resolution：0.01A | |
| Closing Resistor | Range：0 Ω to 2000Ω； Resolution：1 Ω，Precision：1% | |
| Fracture Type | 12-way metal fracture, 6-way closing resistor fracture | |
| Output Power Supply | DC30 V to 250 V digital adjustable / 20 A (instantaneous work) | |
| Dimensions | Host：14.71 in x 11.4 in x 11 in (360 mm × 290 mm × 280 mm3): annex: 11.56 in x 11 in x 8.6 in (370 mm × 280 mm × 220 mm3) | |
| Weight | Host：13.2 lb (6kg): annex：19.8 lb 9kg |
