| Bandwidth | 30 MHz to 125 MHz |
| Sample Rate （real time） | 500 MS/s to 1 GS/s |
| Horizontal Scale (s/div) | 5 ns/div to 100 s/div |
| Channels | 2 + 1 (external) |
| Display | 8 in (203.2 mm) color LCD (800 pixels × 600 pixels) |
| Record Length | 10K to 1M |
| Vertical Resolution (A/D) | 8 bits (2 Channels simultaneously) |
| Vertical Sensitivity | 5 mV/div to 5 V/div (at input), 2 mV/div to 10 V/div (at input) |
| Trigger Type | Edge, Pulse, Video, Slope, Alternate |
| Trigger Mode | Auto, Normal, Single |
| Communication Interface | USB host, USB device, Pass / Fail, LAN, VGA (optional) |
| Battery | Not supported |
| Dimension (W×H×D) | 13.7 in × 6.69 in × 3.07 in (348 mm × 170 mm × 78 mm) |
| Weight (without package) | 3.3 lb (1.50 kg) |
