| Bandwidth | 20 MHz |
| Sample rate (Real time) | 100 MS or s |
| Horizontal Scale (S or div) | 5 ns or div to 100 s or div, step by 1 to 2.5 to 5 |
| Rise time (at input, typical) | ≤17.5 ns |
| Channels | Dual |
| Input impedance | 1 MΩ ±2%, in parallel with 20 pF ±5 pF |
| Probe attenuation factor | 1 X, 10X,100 X,1000 X |
| Max. input voltage | 400 V (PK to PK) (DC + AC PK to PK, 1 MΩ input impedance, Probe attenuation 10:1), CAT II |
| Record length | Max 6000 points on each channel |
| Interpolation | (sin x) or x |
| Input coupling | DC, AC, GND |
| Acquisition modes | Sample, Peak Detect and Average |
| Vertical resolution (A or D) | 8 bits |
| Vertical sensitivity | 5 mV or div to 5 V div (at input) |
| DC gain accuracy | ±5 % |
| DC accuracy (Average) | Average>16: ± (5% reading + 0.05 div) for V |
| Trigger type | Edge, Video |
| Trigger mode | Auto, Normal, Single |
| Trigger level | ±6 divisions from screen center |
| Automatic measurement | Vpp, Vavg, RMS, Frequency, Period, Vmin, V top, Vbase, Width, Overshoot, Pre-shoot, Rise time, Fall time, +Width, -Width, +Duty, -Duty, Delay A→ B↑, Delay A→ B↓ |
| Waveform math | +, -, ×, ÷ |
| Waveform storage | 4 waveforms |
| Lissajous’s figure Phase difference | ±3 degrees |
| Communication interface | USB |
| Cymometer | Unavailable |
| Power supply | 100 V to 240 V AC, 50 Hz to 60 Hz |
| Li-ion battery | 7.4 V, 3500 mAh |
| Full scale reading | 3 digits (Max 4000 to count) |
| Input Impedance | 10 MΩ |
| Capacitance | 51.2 nF t 100 uF: ± (3% ±3 digit) |
| Voltage | VDC: 400 mV,4 V, 400 V: ± (1 ±1 digit) Max input: DC 1000 V, VAC: 4 V,40 V,400 V: ± (1 ± 3 digit), Frequency: 40 Hz to 400 Hz, Max input: AC 750 V (virtual value) |
| Current | DCA: 40 mA, 400 mA: ± (1.5% ±1 digit) 20 A: ± (3% ±3 digit) D AA: 40 mA± (1.5% ±3 digit) 400 mA: ± (2 ±1 digit) 20 A: ± (3% ±3 digit) |
| Impedance | 400 Ω: ± (1% ±3 digit),4 KΩ to 40 MΩ (±1% ±1 digit) |
| Diode | 0 V to 1.5 V |
| On or Off measurement | < 50 (±30) beeping |
| Display | 3.7 in (9.3 cm) color display (640 × 480 pixels) |
