Name: Enviro Test Construct Fluoride Ion Meter -
SKU: ETCLRIM-207

Features

1 Precision benchtop fluoride ion meter is equipped with a large backlit LCD display
2 to 5 points calibration, including the 8 concentration points can be selected
Direct ion concentration readout simplifies the measurement process
Automatic temperature compensation ensures accurate readings over the entire range
Auto-Read function senses and locks the measurement endpoint
Calibration due alarm prompts user to calibrate the meter regularly
Automatic electrode diagnosis shows the calibration points and slopes
Setup menu allows setting the number of calibration points, ionic valency
Reset function automatically resumes all settings back to the factory defaults
Expanded memory stores or recalls up to 500 data sets
USB communication interface is easy to transfer data to PC

Technical Specifications

Ion Concentration Range	0.02 ppm to 1900 ppm and 1 ppm to 35000 ppm
Ion Concentration Resolution	0.001, 0.01, 0.1, 1, automatic
Ion Concentration Accuracy	± 0.5 % F.S.
Ion Concentration Calibration Points	2 points to 5 points
Ion Concentration Calibration Solutions	0.001 / 0.01 / 0.1 / 1 / 10 / 100 / 1000 / 10000
Ion Concentration Measurement Units	ppm, mg/L, mol/L, mmol/L
mV Range	-1999.9 MV to 1999.9 mV
mV Resolution	0.1 mV
mV Accuracy	± 0.2 mV
Offset Calibration	1 point
Calibration Range	Reading ± 10°C or °F
Hold Function	Manual or Auto-read measurement endpoint
Stability Criteria	Low or High
Calibration Due Alarm	1 days to 31 days or off
Memory	Stores up to 500 data sets
Output	USB communication interface
Connector	BNC, 3.5 mm (0.14 in) jack socket
Display	Custom LCD
Power Supply	5 V DC power adapter
Temperature Range	(0 °C to 105°C) 32°F to 221°F
Temperature Compensation	32 °F to 212 °F (0 °C to 100 °C) manual or automatic
Accuracy	±0.9°F (±0.5°C)
Dimensions	8.26 in x7.40 in x 2.36 in (210 mm x 188 mm x 60 mm)
Weight	3.30 lb (1.5 kg)
