Overview
ETC conductivity testers are designed for quick & convenient measurement of material property, such as material separate, quality control, material state check and so on. The products use the electromagnetism testing principle, can testing objects focus on non-ferromagnetic materials. It uses 60 KHz (aviation industry standard) to inspire, the testing data can be read in two kinds of unit (%IACS and MS/m). The products use the high property battery to make sure it keeps more running time; you can easily carry and to grasp hold. More advantages, such as users can replace the probe outdoors.
Features
- Big typeface and the back light illumination designs
- High property battery to make sure it keeps more running time
- Mini size, you could be easy to carry and to grasp hold
- Absolute measurement of electrical conductivity of nearly all non-ferrous metals
- Test the resistivity of conductive materials
- Analyze thermal properties of materials
Technical Specification
| Measurement technology | Eddy current |
| Operating frequency | 60 KHz |
| Instrument case | Anti-intense impact, water-proofing polyester |
| Display screen | Monochrome |
| Power Supply | High capacity, high performance lithium polymer battery |
| Measuring range | 1% IACS to 105% IACS (0.58 MS/m -61 MS/m) |
| Distinguishing range | 0.1% IACS |
| Measuring accuracy | 41°F to 104°F (5 °C to 40 °C) 23% IACS: ±0.5% IACS 100% IACS: ±8% IACS |
| Temperature Compensation | 50 °F to +104 °F (5 ℃ to 40 ℃) |
| Operation Temperature | 50 °F to +104 °F (5 ℃ to 40 ℃) |
| Humidity | 0 to 95% |
| Dimension | 7.08 in x 2.99 in x 1.37 in (180 mm x 76 mm x 35 mm) |
| Weight | 0.66 lb (300 g) |
