Key Features
- LED Backlight
- Stand-By time is 150 hours
- Built-in high speed thermal printer
Technical Specifications
| Measuring head type
| F1 or N1 | |
| Operational principle
| Magnetic induction or Eddy current | |
| Measuring range
| 0~1250μm | |
| Lower limit resolution
| 0.1μm | |
| Indication error
| One-point Calibration
| ±(3%H+1) |
| Two-point Calibration
| ±[(1~3%)H+1] | |
| Measure condition
| The mini. radius of curvature(mm)
| bulge 1.5, concave9 |
| Mini. area dia.(mm)
| Φ7 | |
| Basic critical thickness(mm)
| 0.5 | |
| Working environment
| Temp.
| 0~40°C / 32~104°F |
| Humidity
| 20%~90% | |
| Power supply
| 6V Rechargeable NiMH battery | |
| Outline dimension
| 212×80×32mm (main body) / 8.35×3.15×1.26in | |
| Weight
| 400g | |
| Standard configuration
| Main body, standard test block, basal body, power adapter, Printing paper
| |
| Optional configuration | Other kind of probe, Printing paper | |
