| Feature | Specification |
| Measuring Range | 1.0 to 12,000 mm (0.03 to 472.44 in) |
| Resolution | 0.01 mm (< 100 mm) / 1 mm (> 100 mm) |
| Velocity | 500 to 20,000 m/s (1,640 to 65,616 ft/s), 20 fixed velocities |
| Delay | -20 to 3400 µs, resolution: 0.1 µs |
| Probe Delay | 0 to 99 µs, resolution: 0.01 µs |
| Auto Calibration | Velocity calibration and probe delay calibration |
| Linear Error | Horizontal error ≤ 0.1%, Vertical error ≤ 3% |
| Dynamic Range | ≥ 36 dB |
| Sensitivity | ≥ 64 dB, 200 mm (7.87 in) 2 flat-bottomed hole |
| Pulse | Drive pulse, negative spikes, high/low adjustable |
| Launch Repetition Frequency | Continuously adjustable PFR transmit pulse |
| Matched Damp | 50/150/400 Ù |
| Receiver Measuring Mode | Peak / Verge |
| Bandwidth | 0.3 to 1 / 0.5 to 4 / 2 to 15 MHz |
| Detector Pattern (Gain) | 0 to 110 dB, steps: 0/0.1/0.2/0.5/1/2/6/12 |
| Detector Pattern (Waveform) | RF / Full wave / Positive half-wave / Negative half-wave |
| Display | TFT LCD colour display, 5 brightness options |
| GUI Theme | Simple / Classical / Gray / Bright / Custom themes |
| Screen Update Rate | ≥ 60 Hz |
| Gate | Two separated Gate A/B |
| Measured Value Display | 5 display areas (one main), with selectable values (SA, SB, DA, DB, PA, PB, A%A, A%B, etc.) |
| Alarm | Audible / Visual alarm |
