Overview
Enviro Test Construct Ultrasonic Concrete Crack Depth Test Instrument is a dual-channel, high-precision ultrasonic testing solution designed for analyzing concrete strength and measuring crack depth with superior accuracy. This popular device ranks as the #6 most popular product in Testing Equipment and offers competitive pricing starting at $900, which is lower than 100% of similar items. Built for nondestructive testing applications, this features a 5-inch color LCD screen, robust built-in lithium battery, and 16G internal storage, along with U-disk support for convenient data handling. The lightweight main unit (just 1.35 kg) measures 200 x 144 x 65 mm, making it portable for on-site assessments. The increasing market demand (+31% traffic growth last month) and positive feedback highlight its value and reliability in the field of structural evaluation.
Features
- Dual-Channel Ultrasonic Measurement
- High-Definition 5-Inch Color LCD Display
- Built-In Rechargeable Lithium Battery
- 16G Internal Storage + U-Disk Support
- Lightweight and Compact Main Unit
- Accurate Crack Depth and Concrete Strength Analysis
- Popular Choice in Global Construction Markets
Technical Specifications
| Number of Channels | Dual Channel |
| Display Mode | 5-inch Color LCD Screen (720 × 1280) |
| Storage Capacity | 16 GB |
| Sampling Interval | 25 ns to 2000 µs |
| Sampling Length | 512 points to 2048 points |
| Emission Pulse Width | 0.1 µs to 100 µs |
| Emission Voltage | 125V, 250V, 500V, 1000V (Multi-level Optional) |
| Trigger Circuit | Internal Trigger Mode |
| Transfer Method | Dedicated U Disk |
| Charging Power Supply | AC 100V – 240 V, 50/60 Hz, Output 12.6V DC, 3.0A |
| Host Volume | 7.87 in × 5.67 in × 2.56 in (200 mm × 144 mm × 65 mm) |
| Host Weight | 47.62 oz (1.35 kg) |
