Features
- 120 A max PV charging
- Pure sine wave
- Works with and without battery
- Upgraded MPPT
- Li ion battery
- Built in anti dust kit
- WIFI and GPRS
- LCD display
- RGB lights
Technical Specifications
| Rated Output Power | 6200 W |
| Max. PV Input Power | 6500 W |
| Max. Solar Charging Current | 120 A |
| Nominal DC Voltage Or Max. DC Voltage | 360 VDC or 500 VDC |
| Start-Up Voltage Or Initial Feeding Voltage | 60 VDC or 90 VDC |
| MPPT Voltage Range | 60 to 450 VDC |
| Num. of MPPT Trackers Max. Input Current | 1 22 A |
| Nominal Output Voltage | 220 or 230 or 240 VAC |
| Output Voltage Range | 195.5 to 253 VAC |
| Nominal Output Current | 27.0 A |
| OFF-GRID INPUT (AC） | |
| AC Start-Up Voltage Auto Restart Voltage | 120 to 140 VAC 180 VAC |
| Acceptable Input Voltage Range | 90 to 280 VAC or 170 to 280 VAC |
| Max. AC Input Current | 40 A |
| Nominal Operating Frequency | 50 or 60 HZ |
| Nominal Output Voltage | 220 or 230 or 240 VAC |
| Output Waveform | Pure sine wave |
| Efficiency (DC To AC) | 94 % |
| Nominal DC Voltage | 48 VDC |
| Max. Charging Current (Solar To AC) | 120 A |
| Max. AC Charging Current | 100 A |
| Operating Temperature | 14 °F to 122 °F (- 10℃ to 50 ℃) |
| Size | 16.54 in x 13.78 in x 4.33 in (42 cm x 35 cm x 11 cm) |
| Weight | 19.84 lb (9 kg) |
