Overview
The Enviro Test Construct a portable sampling-type multi-gas detector with an embedded pump and probe. It can monitor up to 6 gases simultaneously, supporting 37 different toxic and flammable gas combinations. Designed to prevent oxygen deficiency, toxic exposure, and explosion hazards, it offers strong worker protection. With IP67 protection, long battery life, and multiple alarms, it ensures reliability in harsh industrial conditions.
Features
- Detects up to 6 gases with 37 gas combination options.
- Embedded pump and probe for accurate sampling.
- Strong protection against oxygen deficiency, toxic poisoning, and explosions.
- Multi-alarm system: LED flashing, vibration, and audible alert.
- Event logging for 30 recent activities, calibration, and bump tests.
- Durable with IP67 water and dust resistance.
- Inner Teflon-coated gas tube line prevents contamination.
- Two filters (in probe & detector) for easy maintenance.
- Long-lasting Li-ion rechargeable battery with 4000mAh capacity.
- Supports IrDA communication and docking station (optional).
Technical Specifications
| Detectable Gases | O₂, CO, H₂S (Electrochemical), Combustible (IR/Pellistor), CO₂ (IR), VOCs (PID) |
| Detection Method | Sampling type with embedded pump & probe |
| Sensor Type | Electrochemical, IR, Pellistor, PID |
| Max Gas Detection | Up to 6 gases (37 combinations) |
| Display | LCD with backlight |
| Alarm Modes | LED flashing, audible alarm, vibration |
| Self-Test | Full function self-test on activation (sensor, pump, battery, circuitry) |
| Event Log | Recent 30 events / bump / calibration |
| Communication | IrDA (infrared) |
| Battery Type | Rechargeable Li-ion, 4000 mAh |
| Battery Runtime | IR sensor: ~5 days continuous, Pellistor: ~30 hours |
| Charge Time | 4–6 hours |
| Low Battery Warning | Alerts at 20, 10, and 5 minutes before shutdown |
| Ingress Protection | IP67 |
| Operating Temperature | -20℃ to +50℃ (-4℉ to +122℉) |
| Operating Humidity | 5–95% RH (non-condensing) |
| Certifications | IECEx: Ex ia IIC T4 Ga / Ex da ia IIC T4 Ga (Expected) |
| Optional Accessories | Docking station, IR link |
| Dimension | 77 × 147 × 54 mm |
| Weight | 400 g (0.88 lbs) |
