Overview
The Portable 6-in-1 Gas Detector is your all-in-one safety companion for industrial, commercial, and environmental monitoring. Compact yet powerful, it detects up to six gases simultaneously with fast response times (<10s) and high accuracy (±2% F.S). Built with advanced technologies (EC, PID, NDIR, Laser, Semiconductor), this handheld detector ensures real-time and reliable measurements in any environment. Its USB data output, 100,000 record storage, and light alarm system make monitoring and reporting simple and efficient. Designed for professionals, it offers long battery life, quick 30s warm-up, and dependable performance even in extreme conditions (-20 °C to 50 °C, high humidity).
Features
- Multi-Gas Detection: Detects up to 6 gases simultaneously with customizable measurement ranges.
- High Accuracy & Reliability: ±2% F.S accuracy, ±1% repeatability, and ≤±1% F.S/year long-term drift.
- Fast Response Time: <10s for standard gases, <20s for some gases.
- Advanced Detection Technologies: EC, Thermal Conductivity, PID, Laser, Semiconductor, and NDIR.
- Data Management: USB output with 100,000 record storage for easy reporting.
- User-Friendly Design: Lightweight handheld model with durable PC housing.
- Smart Alarm System: Light / Light-up alarm for instant hazard alerts.
- Power Efficient: Rechargeable battery with ≤50 mA working current.
- Quick Warm-up: Ready to operate in just 30 seconds.
- Built for Harsh Environments: Operates from -20 °C to 50 °C, 10–95% RH, and standard working pressure (86–106 kPa).
- Compact Size: 230 × 95 × 65 mm (9.06 × 3.74 × 2.56 in) for easy portability.
Technical Specifications
| Type | Handheld / Portable |
| Product Name | Portable 6-in-1 Gas Detector |
| Material | Plastic (PC housing) |
| Alarm Mode | Light / Light Up |
| Accuracy | ±2% F.S |
| Repeatability | ±1% F.S |
| Response Time | <10s (standard), <20s (for some gases) |
| Output | USB, 100,000 storage records |
| Signal Output | USB |
| Working Current | ≤50 mA |
| Power | Rechargeable battery |
| Baud Rate | 9600 |
| Measured Gas | Customizable measurement range |
| Testing Principles | EC / Thermal Conductivity / PID / Laser / Semiconductor / NDIR |
| Size (mm) | 9.06 × 3.74 × 2.56 in |
| Size (Inches) | 9.06 × 3.74 × 2.56 in |
| Temperature Range | -20 ~ 50 °C ( -4 ~ 122 °F ) |
| Storage Temperature | -20 ~ 50 °C ( -4 ~ 122 °F ) |
| Working Pressure | 86–106 kPa |
| Humidity | 10–95% RH (non-condensing) |
| Warm-Up Time | 30s |
| Long-Term Drift | ≤±1% (F.S/year) |
