Overview
This Enviro Test Construct multi-gas detector ensures accurate air quality monitoring with wireless data transmission. It supports up to 64 sensors with cloud and LAN integration for industrial environments. Built with waterproof housing, it operates reliably across extreme conditions. Easy installation and cross-platform apps make it perfect for remote and smart monitoring.
Features
- Real-Time Wireless Monitoring – Transmits PM2.5 and multi-gas readings wirelessly up to 1200m.
- Multi-Sensor Support – Connect up to 64 wireless sensors in a single system.
- Triple Data Access – View data via LAN, Internet, and G7 Client Apps (Windows, iOS, Android).
- High Accuracy – Supports 4–20mA/0–5VDC analog sensor inputs with instant data transmission.
- Long Battery Life – Average 1–2 years per sensor with low power consumption (<130mA).
- Durable & Waterproof – Designed with waterproof housing for industrial and laboratory use.
- Wide Operating Range – Functions in extreme conditions (-31°F to 167°F / -35°C to 75°C).
- User-Friendly Software – G7-Centre and G7-Client apps for live monitoring, alerts, and data storage.
- Customizable Options – OEM/ODM support for branding, packaging, and software re-engineering.
- Secure & Reliable – Unique 8-digit sensor ID and encrypted Modbus TCP protocol communication.
Technical Specifications
| RF Wireless Frequency | 433 MHz |
| RF Wireless Speed | 4.8 Kbit/s |
| RF Power | 10 dBm |
| RF Address/Band | 255 / 15 |
| Signal Input | 4–20mA / 0–5VDC |
| Network Port | 10/100M Ethernet |
| Transmission Interval | User programmable (5s – 4h) |
| Data Packet | Instant real-time update of connected sensors |
| Sensor ID | Unique 8-digit identification |
| Target Gas | PM2.5 & Multi-gas (CO₂, leaks, toxic gases) |
| Application | Industrial, Laboratory, Environmental Monitoring |
| Display Type | Analog + Digital |
| Certificates | CE, RoHS |
| Customized Support | OEM, ODM, Software Re-engineering |
| Warranty | 2 Years |
| Operating Temperature | -31°F ~ 167°F (-35°C ~ 75°C) |
| Dimension (Base Station) | 115 × 90 × 55 mm (4.52 × 3.54 × 2.16 in) |
| Dimension (Sensor Unit) | 70 × 65 × 35 mm (2.75 × 2.55 × 1.37 in) |
| Material | Plastic Body + Waterproof Metal Housing |
| Color | White |
| Power Rating | <130mA |
| Battery Life | 1–2 Years Average |
| Weight | N/A (lightweight portable unit) |
