Hybrid Off-Grid 48 V 6 KW 6.2 KW 6 KVA Solar Inverter With 98% Efficiency – Enviro Test Construct

High-efficiency inverter with 98% peak efficiency (PV to INV) and 94% (BAT to PV). Supports 48 VDC batteries, 27A max solar input, and reliable low DC cut-off at 44 VDC.

SKU: ETCSI-148 Category:

Technical Specifications

Nominal Voltage220 VAC to 230 VAC ± 5%
Surge Power2 x rated power for 5 seconds
Frequency50 Hz or 60 Hz
WaveformPure Sine Wave
Transfer Time10ms typical (UPS)
20ms typical (Appliances)
Peak Efficiency (pv to inv)98 %
Peak Efficiency (batt to pv)94 %
Battery Voltage48 VDC
Cold Start Voltage46 VDC
Low DC Cut-Off Voltage44 VDC
Maximum Solar Input Current27 A
Maximum Solar Charge Current120 A
Maximum AC Charge Current80 A
Maximum Charge Current120 A
Size17.2 in x 11.6 in x 4.13 in (43.8 cm x 29.5 cm x 10.5 cm)
Net Weight19.18 lbs. (8700 g)
