High-Precision Micro Ohm Meter with 100A Output – Enviro Test Construct
High-Precision Micro Ohm Meter with 100A Output – Enviro Test Construct - Image 2
High-Precision Micro Ohm Meter with 100A Output – Enviro Test Construct - Image 3

High-Precision Micro Ohm Meter with 100A Output – Enviro Test Construct

High-Precision Micro Ohm Meter with 100A Output measures low resistance with 0.01mΩ resolution, 0.5% accuracy, LCD display, and 80-group data storage.

SKU: ETCBCM-303 Category:

Technical Specifications

ProjectTechnical Parameters
Measuring Range Of Resistance IMeasuring Range Of Resistance II
Output Current: 50A0 m W to 800 m W800 m W to 2000 m W
Output Current: 100A0 m W to 400 m W400 m W to 2000 m W
Resolution0.01 m W0.1 m W
Power SupplyAC 220 V, 50 Hz
Output Current50 A and 100 A
Accuracy≤ 0.5%
Storing Data80 groups
DisplayLarge graphic LCD with wide temperate back light
Dimension13.3 in x 12.9 in x 9 in (340 mm x 330 mm x 230 mm)
Weight17.8 lb (8.1 kg)
