Technical Specifications
| Maximum Voltage (Between Any Terminal And Earth Ground) | 100 V |
| Battery Type | 2 AA alkaline batteries |
| Operating Altitude | 1.86 mi (3000 m) |
| Storage Altitude | 7.46 mi (12000 m) |
| Jaw Opening | 1.3 in (34 mm) |
| Flexible Current Probe Diameter | 0.29 in (7.5 mm) |
| Flexible Current Probe Cable Length | 5.9 Ft (1.8 m) |
| Safety | Pollution degree 2 CAT III 1000 V or CAT IV 600 V or CAT III 100r0 V or CAT IV 600 V |
| IP Rating | IP30 |
| Electromagnetic Compatibility | Portable electromagnetic environment Class A equipment (industrial broadcasting and communication equipment) |
| Operating Humidity | Non-condensing (<50 ℉ (10 ℃), ≤90% RH (at 50 ℉ to 86 ℉ (10 ℃ to 30 ℃)), ≤75% RH (at 86℉ to 104 ℉ (30 ℃ to 40 ℃)), ≤45% RH (at (104 ℉ to 122 ℉ (40 ℃ to 50 ℃)) |
| Temperature Coefficients | Add 0.1 x specified accuracy for each degree C above 82.4 ℉ to 64.4 ℉ (28 ℃ to 18 ℃) |
| Operating Temperature | 14 ℉ to 122 ℉ (-10 ℃ to 50 ℃) |
| Storage Temperature | -40 ℉ to 140 ℉ (-40 ℃ to 60 ℃) |
| Dimensions | 9.8 in x 3.3 in x 1.7 in (24.9 cm x 8.5 cm x 4.5 cm) |
| Weight | 0.87 Ib (0.395 Kg) |
