| Basic Accuracy | 0.1% |
| Test Frequency | 100 Hz, 120 Hz, 1 kHz, 10 kHz |
| Test Parameters | L, C, R, Z, D, Q, X, θd, θr, Vm, Im, △% |
| AC Test Signal Level | 0.1 Vrms, 0.3 Vrms, 1 Vrms |
| Signal Source Internal Resistance | 10 Ω or 100 Ω |
| Test Terminal Configuration | 5-terminal |
| Test Speed | Fast: 19 ms, Medium: 83 ms, Slow: 333 ms, ≤120 Hz Fast: 4XT+3 ms |
| Zero Clearing | Open, Short, Load |
| List Sweep | 10-point list sweep with multi-frequency combined test sorting |
| Equivalent Circuit | Series or Parallel |
| Range Mode | Auto or Hold |
| Trigger Mode | Internal, External, Manual or Bus |
| Average Times | 1 to 255 |
| Arithmetic Operation | Direct reading, △ABS, △% |
| Delay | Trigger delay or step delay: 0 to 60 s (1 ms step) |
| Comparator | 10 bins sorting with PASS or FAIL indication via front panel LED |
| Storage | 100 instrument setting files and 10 measurement results |
| External Storage | USB interface for setting file and CSV data export |
| Power Supply | 110 V AC or 220 V AC |
| Operating Temperature Range | 32 °F to 104 °F (0 °C to 40 °C) |
| Dimensions | 18.5 in x 14.6 in x 9.1 in (47 cm x 37 cm x 23 cm) |
| Product Weight | 15.4 lb (7 kg) |
