Key Features
1.Customaries curve for a specific testing material
2.LCD display of 128×32 matrix with Backlight
3.Converts to all common hardness scales(HV ,HB,HRC,HRB,HRA,HS).
4.Easy to use Menu driven system
5.With USB interface, multiple communication modes are adopted to meet customized requirements of various users.
6.Max 1000 groups of data can be stored in memory.
7.Upper and lower limit of hardness can be preset; with alarm
8.Test values software calibration function.
9.Working voltage: 3.7V Rechargeable Li-Ion battery
10.Continuous working period: approx. 200 h (no back light on).
Technical Specifications
| Measuring range | HLD（170～960）HLD |
| Measuring direction | 360° |
| Hardness scale | HL, HB, HRB, HRC, HRA, HV, HS |
| Display | LCD, 128×32 matrix LCD |
| Data memory | : up to 1000 groups 6.Range |
| Range of upper and lower limit | the same as measuring range |
| Battery | Rechargeable Li-Ion battery |
| Communication interface | USB |
| Continuous working period | approx. 200 h (no back light on) |
| Dimension | 5.5 x 3.1 x 39 in (142×80×39mm) |
| Weight | 1.1lbs.(0.5kg) |
