| Specification | Details |
| Accuracy | ±1% of reading at rates >0.2 mps |
| Repeatability | 0.2% |
| Principle | Transit-time |
| Velocity | up to 32 m/s |
| Pipe Size | DN15mm to DN6000mm |
| Display | LCD with backlight, shows accumulated flow/heat, instantaneous flow/heat, velocity, time |
| Signal Output | 4-20mA, OCT pulse, relay |
| Signal Input | 3x 4-20mA for heat measurement with PT100 |
| Functions | Records forward/reverse/net flow and heat, power-on/off times, last 30 readings, data via Modbus |
| Pipe Material | Carbon steel, stainless steel, cast iron, cement, copper, PVC, aluminum, FRP; liner allowed |
| Straight Pipe Section | Upstream 10D, Downstream 5D, From pump 30D |
| Liquid Types | Water, sea water, industrial sewage, acid/alkali, alcohol, beer, oils that transmit ultrasonic waves |
| Liquid Temperature | Standard -30°C to 90°C, High-temp -30°C to 160°C |
| Liquid Turbidity | <10000ppm, minimal bubbles |
| Flow Direction | Bi-directional, net flow/heat |
| Environment Temp | Main -30°C to 80°C, Transducer -40°C to 110°C |
| Humidity | Main 85% RH, Transducer IP65 (IP68 optional) |
| Cable | Twisted pair, 5m standard, extendable to 500m; RS485 up to 1000m |
| Power Supply | AC220V or DC24V |
