Features
- High Accuracy: ±1% with 0.2% repeatability
- Wide Pipe Range: DN15–6000mm
- Portable & Handheld: Compact rechargeable design
- Data Logging: Built-in logger for flowrate records
- Versatile Measurement: Handles waste liquid and clean water
- Fast Response: 0.5s measurement period
- User-Friendly Display: LCD with backlight
- Low Power Consumption: Less than 1.5W
Technical Specification
| Specification | Details |
| Pipe Size | 0.59 in to 236.22 in (15mm to 6000mm) |
| Power Consumption | Less than 1.5 W |
| Measurement Principle | Transit-time measurement principle |
| Power Supply | 90 to 230V AC |
| Output | RS232C |
| Accuracy | 1% |
| Repeatability | 0.20% |
| Measurement Period | 0.5 s |
| Display | LCD with backlight, 2*20 letters |
| Liquids Temperature | -40 to 320 °F (-40 to 160 °C) |
