Technical Specification
| Measuring range | 39.37 in Ω to 78700.78 in Ω (1000 mm Ω to 1999000 mm Ω) |
| Resolution | 39.37 in Ω (1000 mm Ω) |
| Test current | DC 1 A,2 A,5 A, 10 A four fixed current gears |
| Measurement accuracy | ±(0.5%+2d) |
| Measuring radius | 1968.50 in (50 cm) |
| Display mode | Three-half LCD display |
| Working mode | continuous |
| Working power supply | AC 220V ±10%, 50 Hz |
| Working Environment | Temperature: 50 oF to 104 oF (10 °C to 40 °C) |
| Relative humidity | Humidity: ≤80% RH≤80% |
| volume | 11.81 in x 10.62 in x 7.87 in (300 mm x 270 mm x 200 mm) |
| weight | 11.02 lb (5 kg) (without accessories) |
