Overview
Enviro Test Consrtuct Ultrasonic Thickness Gauge display uses OLED, has the characteristics of self-luminous, full visual angle, wide temperature and it can assure high linear measurement.
Technical Specifications
| Measuring Range | ±20 μm, ±40 μm, ±80 μm |
| Highest Resolution | 0.001 μm |
| Filter | RC, PC-RC, GAUSS, D-P |
| Sampling Length L | 0.01 in (0.25 mm), 0.03 in (0.8 mm), 0.1 in (2.5 mm) |
| Evaluation Length L | (1 I to 5 I) (optional） l is sampling length |
| Maximum Drive Stroke | 0.7 in (17.5 mm) |
| Minimum Drive Stroke Length | 0.05 in (1.3 mm) |
| Running Length | 0.05 in to 0.69 in (1.3 mm to 17.5 mm) |
| Indication Error | ≤ ±10% |
| Indicated Value Variability | ≤ 6% |
| Display Mode | 128 × 64 OLED Lattice liquid crystal (self-luminescent) |
| Power | Built-in rechargeable lithium battery |
| Dimension | 5.51 in x 2.05 in x 1.89 in (140 mm × 52 mm × 48 mm) |
| Weight | 0.97 lb. (440 g) |
