Overview
Enviro Test Consrtuct Probe Magnetic Coating Thickness Gauge can test magnetic thickness method, can be non-destructively measuring magnetic metal matrix (such as: steel, iron, nickel) on non-magnetic coatings thickness (such as: galvanized, chrome, paint, electrophoresis, enamel, rubber, powder coating, enamel, etc.)
Features
- The use of alloy integrated probe, the world’s leading technology
- Simple operation, fast testing speed and high sensitivity
- Exquisite artificial integration design, easy to carry
- Two test methods: continuous testing (CONT INUE) and single (SINGLE) measurement
- Statistical functions: maximum (MAX), minimum (MIN), average (MEA)
- Which can store 2000 measurement data (10 sets of data)
- Can connect to the computer for communication, read out and store data for preservation or printing
- Two calibration modes: zero calibration and two-point calibration
- There are beep prompts in operation process (single measurement mode).
- Automatic identification of iron-based and non-ferrous base materials
- Low voltage indication
- Manual / automatic shutdown function
- Super LCD display backlight, with screen rotation inversion function.
- Unit conversion μm/mi
Technical Specifications
| Measuring Range | 0 μm to 1500 μm |
| Operating Temperature | 0 ℃ to 50 ℃ (32 °F to 122 °F) |
| Operating Humidity | 20% RH to 90% RH |
| Minimum Surface Thickness | 0.016 in (0.4 mm) |
| Measurement Accuracy | ± (3% H+1.5 μm) |
| Resolution | 0.1μm/1μm |
| Minimum Curvature | Bugle 5mm; Concave 25mm |
| Minimum Surface Area | 0.71 in x 0.59 in (18 mm x 15 mm) |
| Power Supply | 3 x AAA alkaline batteries |
| Dimensions | 4.96 x 2.52 x 1.10 in (126 mm x 64 mm x 28 mm) |
| Weight | 0.234 lb. (106 g) (excluding battery) |
