Overview
Enviro Test Consrtuct metal thickness meter is a professional non-destructive testing instrument used to measure the thickness of nonmagnetic coatings and coatings on the surface of magnetic metal materials such as steel. Use the principle of magnetic induction measurement for fast non-destructive measurements.
Technical Specifications
| Measuring Range | 0 to 1250 μm |
| Minimum Contact Area | Φ 4.5 in (Φ 11.5 mm) |
| Measurement Accuracy | ± (1% to 3%) H＋1.5 μm |
| Thinnest Substrate | 0.1 in (0.3 mm) |
| Minimum Curvature | Convex Convex (5 mm) Concave Concave (25 mm) |
| Resolving Power | 0.1 μm / 1 μm |
| Power | Three alkaline batteries |
| Size | 5.1 in x 2.7 in x 0.9 in (130 mm × 70 mm × 25 mm) |
| Display | 2.3 inch color screen |
| Weight | 0.22 lb (100 g) |
| Using Environment | 32°F to 140°F (0℃ to 60℃) 20% RH to 90% RH |
