Overview
Enviro Test Consrtuct high accuracy vibration meter sends a sweeping excitation signal through the controller to excite the sensor steel string oscillation, which generates an induced electric potential, which is processed by the acquisition circuit and finally converted into a digital signal output, which includes frequency and temperature information.
Technical Specifications
| Screen | 4.3 in (10.92 cm) resistive screen, 480 x 272 dot matrix |
| Measuring Range | 400 Hz to 3800 Hz |
| Resolution | 0.01 Hz |
| Flash | 32 MB |
| Working Time | 10 hours at 77 °F (25 °C) (approximate) |
| Lithium Batteries | 7.2 V, 4500 mAh |
| Dimension | 6.14 in x 4.80 in x 1.42 in (156 mm x 122 mm x 36 mm) |
| Weight | 1.65 lb (0.75 kg) |
