Overview
Enviro Test Consrtuct electroplating thickness is a split coating thickness gauge integrating magnetic and eddy current. It can measure coating thickness quickly, without damage and accurately. It can be used in both laboratory and project
site. It is widely used in metal processing, chemical industry, commodity inspection, electroplating, spraying, pipeline corrosion protection, aluminum profile, steel structure and other industries, as well as shipbuilding, aerospace, electric power, boiler special inspection, technical supervision bureau and other industries.
Features
- Two thickness measurement methods
- There are three measurement modes
- With temperature compensation function
- There are five statistics
- Connection between sensor and instrument
- Coating thickness via Bluetooth
Technical Specifications
| Customized Support | OEM |
| Working Principle | Magnetic induction / eddy current |
| Measuring Range | 0 to 1500 μm |
| Resolution | 0.1μm (0 to 99μm ) |
| Indication Value | ± (3% H + 1) |
| Two Point Calibration Indication Error | ± [(1 to 3)% H + 1] |
| Minimum Radius | 0.1 in (3 mm) |
| Diameter Of Minimum Area | 0.2 in (7 mm) |
| Critical Thickness Of Matrix | 0.19 in . 0.11 in (0.5 mm / 0.3 mm) |
