Features
- E-Fashionable Style; Energy-saving; Waterproof Keyboard; Simple-using
- Normal Mode: Used for measuring of material thickness
- Coating Thickness Mode: Used as a coating thickness gauge for measuring the coating thickness
- Auto adjustment for the measuring accuracy
- Auto recognition for different types of probes
Technical Specifications
| Specifications | Details |
| Measurement Range | Launch-echo mode, 1 mm to 500 mm (according to the specific probe); echo-echo mode, 0.11 in to 0.78 in (3 mm to 20 mm) (E-E10 probe) |
| Sound Speed Range | 1000 m/s to 9990 m/s |
| Display Digits | Four Digits |
| Indication Accuracy | 0.1 mm (measurement greater than 100mm); 0.01 mm (measurement less than 100mm) |
| Measurement Error | H < (0.39 in) 10 mm, ± 0.05; H ≥ (0.39 in) 10mm, ± (0.01 + H / 200). (H is the measured thickness value) |
| Use Environment | Temperature: 14 °F to 140 °F (-10 ℃ to 60 ℃); relative humidity less than 90 %. |
| Measurement Method | Manual Storage Measurement |
| Storage Capacity | Divided into 6 groups, each group has 100 measurement points, a total of 600 measurement points |
| Dimensions | 5.74 in × 3.18 in × 1.18 in (146 mm x 81 mm x 30 mm) |
| Weight | 0.66 lbs (300 g) |
