Features
- Two measuring methods: magnetic induction (F) and eddy current (N)
- Two measurement mode: Single and Continuous(Notice:Continuous mode is convenient to measure the coating thickness of curved objects and tiny objects
- Metric/imperial system selectable
- Manual or automatic shut down
- Auto memory of calibration value,and auto recognize the substrate
- Operation process have buzzing reminder,while no buzzing in continuous mode
- Use “USB data output” and “RS-232 data output” to connect with PC
- Provide “Bluetooth ™ data output” choice
- Integral Type suitable for single-hand operation, large probe with large contact surface have better stability, users can get continuous, good repetitive and precise measurements
Technical Specifications
| Operating Principle | Magnetic Induction / Eddy Current (F / NF) |
| Measuring Range | 0 um to 1250 um / 0 mil to 50 mil |
| Resolution | 0.1 um / 1 um |
| Min. Measuring Area | 0.24 in (6 mm) |
| Min. Sample Thickness | 0.011811 in (0.3 mm) |
| Accuracy | ± 1 to 3% n or ± 2.5 um |
| Metric / Imperial | Convertible |
| Battery Indicator | Low Battery Indicator |
| Operating Conditions | 32 °F to 104 °F (0 °C to 40 °C) |
| Power Supply | 4 x 1.5 V AAA (UM-4) Battery |
| Dimensions | 4.96 in x 2.55 in x 1.06 in (126 mm x 65 mm x 27 mm) |
| Weight | 0.17 lb (81 g) |
