Features
- 9-inch HD display screen
- Flashlight function
- Fall alarm function
- Screenshot to save data
- USB charging port
- Multiple gas display units
Technical Specifications
| Gas Detected | Ammonia NH3 | |
| Detection Principle | Electrochemical principles(FLUE GAS SENSOR) | |
| Measure Range | 0 ppm to 100 ppm or 200 ppm or 500 ppm or 1000 ppm(other options 0 ppm to 2000 ppm, 5000 ppm 0 ppm to 10 ppm) | |
| Resolution | 0.01 ppm | |
| Precision | 2% FS | |
| Sampling Method | Built-in stable flow pump, flow range: 0 ML/Min to 500 ML/Min | |
| Modular Structure | Can detect up to 1 to 4 kinds of gases | |
| Concentration Unit | ppm, mg/m3, %VOL, %LEL, can be switched by one button | |
| Display | 3.5-inch colour display, resolution 320 x 480 | |
| Display Mode | Multiple display modes select-able: multi-channel data mode, multi-curve mode, single channel + single curve mode | |
| Data Storage | Standard 16 M capacity storage function, can save up to 100000 groups of data. Can be directly connected to the computer through USB, quickly download stored data, EXCEL format | |
| Wireless Transmission | (optional) Bluetooth (with printer), ZigBee, built-in DTU wireless module (optional) | |
| Built-in printer or external Bluetooth printer (optional with extra charge) | ||
| Operating Language | Chinese and English | |
| Battery Capacity | 3800 mA rechargeable | |
| Charging Interface | USB charging interface, 5 V or 2 A standard charger | |
| Filter Device | Equipped with a multi-layer filter to efficiently filter oil, water and dust. | |
| Wireless Network | Bluetooth (with print function), ZigBee, Lora+ (relay DTU), DTU (optional with extra charge) | |
| Network Frequency | Lora 0.02 mi (470 M), DTU (2.4 G) (optional with extra charge) | |
| Wireless Trans. Distance | Lora 0.99 mi(1.6 km), DTU (unlimited) (optional with extra charge) | |
| Response Time | ≤ 8S | |
| Repeatability | ≤ ± 1% | |
| Zero shift | ≤ ± 1% (F.S / Year) | |
| Working Humidity | 0% RH to 95% RH (no condensation) (high humidity can be selected with filter drying device) | |
| Explosion-Proof | Exic II CT3, GC | |
| Alarm Mode | Buzzer, LED, and alarm status prompt on the display, fault alarm, pump abnormal alarm, battery low battery alarm, shutdown alarm, fall alarm (optional with extra charge) | |
| Recovery Time | ≤ 10 S | |
| Linearity Error | ≤ ± 1% | |
| Degree Of Protection | IP66 | |
| Standard Accessories | Manual, warranty card, power charger, carrying case, water and oil filter, data cable | |
| Optional Accessories | Bluetooth printer, pressure sensor, high temperature rod, Metal extension rod, Bendable rod , Silicone hose, dry filter device, PC download software | |
| Operating Temperature | 68 F to 122 F (-20°C to 50°C) (optional flue gas sampling probe, up to 1112 F (600°C), 2192 F (1200°C) smoke concentration) | |
| Dimensions | 10.63 in x 2.95 in x 1.61 in (270 mm 75 mm x 41 mm) | |
| Weight | 0.88 lb. (0.4 kg) | |
