Technical Specifications
| Measurement Range | ± 0.0 3m per second to ± 5 m per second |
| Accurate | 1 % |
| Repeat Accuracy | 0.2 % |
| Measuring Pipe Diameter | 0.9 in to 47.4 in (25 mm to 1200 mm) |
| Outlet | Analog output 4 mA to 20 mA, max load 750 Ω, pulse output 0 KHz to 10 KHz |
| Newsletter | RS232 & RS485 Modbus |
| Save | TF card (expandable to 8 G, note that it can be used for 12 years by sending data once every 60 seconds) |
| Power Supply | 10 V to 36 V DC or 1 A |
| Monitor | 9.4 in x 5.0 in (240 mm x 128 mm) LCD |
| Protection Class | Transmitter PC or ABS IP65, Sensor IP68 |
| Cable | Twisted shielded cable, standard length 29.5 ft (9 m), can be extended to 0.1 mi (274 m) |
| Operating Temperature | Transmitter 68 °F to 140 °F (20 °C to 60 °C), sensor -40 °F to 176 °F (-40 °C to 80 °C) Standard |
| Measurement Environment | Up to 99 % RH, non-condensing |
