Features
- 5 ” full color screen, allows for detailed showing of infrared generated images;
- 320×240 resolution and 0.3-million-pixel visible image resolution, high definition of images;
- 20 to 400° / – 4° to 752° temperature measurement range, 2.5 degrees accuracy for better operation;
- 5 kinds of palette for choice: rainbow, iron red, cold color, black & white and white & black;
- Automatic setting: 5 minutes / 20 minutes / not power off automatically;
- Built-in 8GB SD card for storage, the pics can be also transferred to television, computer or other devices for checking;
- Wide application at firefighting, archaeology, traffic, farming, electronic manufacture and other fields;
- Separate button for specific function, which is quite easy for you to turn it on or off, delete or check pictures;
- Mini and portable for 3.81 in x 5.07 in x 10.07 in size and 20.74 oz weight, attached pouch allows for more convenient carrying;
- Ergonomic handle, which can be used and held comfortably
Technical Specifications
| Display screen | 3.5 ″ full angle TFT display screen |
| Infrared image resolution | 320 x 240 |
| visible image resolution | 300,000 px |
| Field angle/shortest focus length | 56 degrees x 42 degrees / 0.15 m |
| Emissivity | Adjustable from 0.01 to 1.0 |
| Frame rate of thermal image | 9 Hz |
| Wavelength coverage | 8 um to 14 um |
| Focus mode | Fixed |
| Storage medium | Built-in 3 G (above 20 thousand images stored) |
| File format | JPG |
| USB | Micro USD 2.0 |
| Power supply | Built-in chargeable 26650 battery |
| Accuracy | ± 3.6 ℉ (± 2 °C) or ± 2 % of reading |
| Relative humidity | < 85 % RH |
| Best Focus distance | 1.64 feet (0.5 m) |
| Work temperature | 32 °F to 113 °F (0 ℃ to 45 ℃) |
| Storage temperature | – 4 °F to 140 °F (- 20 ℃ to 60 ℃) |
| Temperature measurement range | – 4 °F to 752 °F (- 200 °C to 400 °C) |
| Product size | 3.81 in x 5.07 in x 10.07 in (9.7 cm x 12.9 cm x 25.6 cm) |
| Product weight | 20.74 oz (588 g) |
