Features
- User-friendly with guided operation display
- Auto-ranging for high-resolution measurements
- Easy data export via USB
- Extensive data storage capacity
- Versatile probe for wide conductivity range
- Intuitive graphical interface for effortless navigation
- Precise calibration with standard solution recognition
- Ample memory for storing thousands of data sets
- Wide measurement ranges for various parameters
- Excellent accuracy for reliable resultsTop of Form
Technical Specifications
| Parameters | Conductivity, Resistivity, TDS, Salinity, Ash Content, Temp. | Conductivity, Resistivity, TDS, Salinity, Temp. | |
| Range | Conductivity | 0.000 μS/cm to 3000 mS/cm | 0.000 μS/cm to 1000 mS/cm |
| Resistivity | 5.00 Ω·cm to 100.0 MΩ·cm | 5.00 Ω·cm to 100.0 MΩ·cm | |
| TDS | 0.000 mg/L to 1000 g/L | 0.000 mg/L to 300 g/L | |
| Salinity | 0.00% to 8.00% | 0.00% to 8.00% | |
| Ash Content | 0.0000 to 100.0% | / | |
| Temperature | 23.0 °F to 266.0 °F (-5.0 ℃ to 130.0 ℃ ) | 23.0 °F to 221.0°F ( -5.0 ℃ to 105.0 ℃) | |
| Accuracy | Conductivity | ±0.5% FS | ±1.0% FS |
| Resistivity | ±0.5% FS | ±1.0% FS | |
| TDS | ±0.5% FS | ±1.0% FS | |
| Salinity | ±0.01% | ±0.2% | |
| Ash Content | / | / | |
| Temperature | ±0.18 °F (±0.1 ℃) | ±0.36 °F (±0.2 ℃) | |
| Calibration | Up to 5 points | Up to 2 points | |
| Cell constant(K) | Select from K = 0.01, 0.1, 1.0 or 10 | Select from K = 0.01, 0.1, 1.0 or 10 | |
| Temp. Compensation | Auto & Manu 23.0 °F to 266.0 °F ( -5.0 ℃ to 130.0 ℃) | Auto & Manu 23.0 °F to 221.0 °F ( -5.0 ℃ to 105.0 ℃) | |
| Power Supply | Li-on (DC 3.8 V) | Li-on (DC 3.8 V) | |
| Standard Configuration | DJS-1-L Platinum black conductivity electrode, T-818-L ATC probe Li-on (DC 3.8 V)-built-in Field carrying case | DJS-1-L Platinum black conductivity electrode, T-818-L ATC probe Li-on (DC 3.8 V)-built-in Field carrying case | |
| Optional Accessories | Standard solution K=0.01,1.0(bright).0.1 or 10 conductive probe Stirrer and Electrode holder | Standard solution K=0.01,1.0 (bright).0.1 or 10 conductive probe Stirrer and Electrode holder | |
| Dimension & Weight | 9.29 in x 14.76 in x 8.27 in (490 mm x 375 mm x 210 mm) 11.0 lb (5 kg) | 9.29 in x 14.76 in x 8.27 in (490 mm x 375 mm x 210 mm)11.0 lb (5 kg) | |
