Overview
This instrument can be used in constructio period,but also can be used as the long-term safety monitoring project. comply with the dam safety monitoring technology standard.
Technical Specifications
| Prode Diameter | 0.55 in (14 mm) |
| Conductor | 0.27 in x 0.07 in (7 mm x 2 mm) tinned copper wire |
| Insulation Material | PE |
| Power | 9 V Battery |
| Ruler Cable | PE or PU coated |
| Probe Length | 8.66 in ( 220 mm) |
| Dept Of The Measurement (m) WLM 30 | 0 ft to 98.42 ft (0 m to 30 m) |
| Dept Of The Measurement (m) WLM 50 | 0 ft to 164.04 ft (0 m to 50 m) |
| Dept Of The Measurement (m) WLM 100 | 0 ft to 328.08 ft (0 m to 100 m) |
| Dept Of The Measurement (m) WLM 150 | 0 ft to 0.093 mi (0 m to 150 m) |
| Dept Of The Measurement (m) WLM 200 | 0 ft to 0.124 mi (0 m to 200 m) |
| Dept Of The Measurement (m) WLM 300 | 0 ft to 0.186 mi (0 m to 300 m) |
| Dept Of The Measurement (m) WLM 400 | 0 ft to 0.248 mi (0 m to 400 m) |
| Dept Of The Measurement (m) WLM 500 | 0 ft to 0.31 mi (0 m to 500 m) |
| Minimum Indication (mm) | 0.03 in (1.0 mm) |
| Power Supply (V) | DC 9 |
| Repeat Indicator (mm) | + 0.07 in (+ 2.0 mm) |
| Weight (kg) WLM 0 | 9.92 lb (4.5 kg) |
| Weight (kg) WLM 50 | 12.12 lb (5.5 kg) |
| Weight (kg) WLM 100 | 14.33 lb (6.5 kg) |
| Weight (kg) WLM 150 | 16.53 lb (7.5 kg) |
| Weight (kg) WLM 200 | 18.73 lb (8.5 kg) |
| Weight (kg) WLM 300 | 22.04 lb (10 kg) |
| Weight (kg) WLM 400 | 26.45 lb (12 kg) |
| Weight (kg) WLM 500 | 33.06 lb (15 kg) |
