Features
- Flameproof and explosion-proof design
- SO2 gas leak detector, sulfur dioxide gas meter
- Easy installation
- Factory produces
Technical Specifications
| Power Supply | 24 V DC or AC 220 V or 50 Hz |
| Output Signal | 4 mA to 20 mA standard industrial signal output |
| Display | Backlight LED |
| Backlight LED Display | 4-digit gas reading |
| Relative Humidity | 15 % to 90 % RH (non-condensing) |
| Atmospheric Pressure | 86 Kpa to 106 Kpa |
| Explosion-Proof Grade | Exibd II CT6 |
| Distance | 0.62 mi (1000 m) |
| Detection Gas | NH3 |
| Range | 0 ppm to 100 ppm |
| Accuracy | ±5 % (F.S) |
| 90% Response Time | ≤ 50 s |
| Min Readout | 1 ppm |
| Low Or High Alarm | 25 ppm or 50 ppm |
| Operating Temperature | -4 °F to 122 °F (-20 °C to +50 °C) |
| Weight | 6.61 Ib (3 kg) |
| Size | 6.3 in x 4.96 in x 3.07 in (160 mm x 126 mm x 78 mm) |
